HSU-14HFTEX/013WUSDC-T3 WHITE

T3 Compressor-53°C FULL BTU’s

The powerful T3 Compressor gives Full Btu’s even at an extreme temperature of 53°C.

15sec Instant Cooling

With cutting-edge PKC and KTS technologies, this system delivers rapid performance, cooling in just 15 seconds and heating in only 30 seconds for instant comfort.

1.2A Energy Saving

The AC regulates compressor current as low as 1.2A in dehumidification mode, achieving up to 60% energy savings while enhancing overall efficiency.

Performance Specifications

Capacity wise:

1-Ton
Category wise:

DC Inverter
Color:

Ocean White
Cooling Capacity BTU:

14500
Running Current Cooling (A):

1.6 ~ 5.3
Power input Cooling (KW):

0.36 ~ 1.19
Heating Capacity BTU:

14700
Running Current Heating (A):

1.6 ~ 6.0
Power Input Heating (KW):

0.57 ~ 1.35

Other Parameters

Input Power Supply (Ph, VAC, Hz):

1PH,230V ̴, 50Hz
Air Flow Volume (m3/h):

750
Refrigerant Type:

R-32
Refrigerant Amount (G):

800

Indoor & Outdoor Parameters

Indoor Net Dimension (L*W*H) mm³:

850*295*210
Indoor Packing Net Dimension (L*W*H) mm³):

952*389*283
Indoor Net Weight (kg):

11.5
Indoor Gross Weight (kg):

14.1
Outdoor Net Dimension (L*W*H) mm³:

800*345*560
Outdoor Packing Net Dimension (L*W*H) mm³:

908*405*625
Outdoor Net Weight (kg):

28
Outdoor Gross Weight (kg):

31

Features

Cooling:

Yes
Heating:

Yes
Dry:

Yes
Vertical Flapper Auto Swing:

Yes
Horizontal Louvers Auto Swing:

Yes
Air-Purification With UV Technology:

No
WiFi:

Yes
Self-Clean:

Yes
Anti-Corrosion:

Yes
Turbo Function:

Yes
ECO Mode:

Yes

Accessories

Installation Kit (Liquid side) Material*Length*Dia*Thickness (mm):

Copper * 2920*6*0.65 (6mm)
Installation Kit (Gas side) Material*Length*Dia*Thickness (mm):

Copper * 2920*12*0.65 (12mm)
Power Cable (Core*mm²):

3*2.5
Communication Cable b/w Indoor & Outdoor (Core*mm²):

4*2.5
